3. Carry out gas analysis
If the calibration has been successfully completed and all previous queries have been
answered, the instrument is ready for operation.
Hint
The following minimum times must be observed in order to obtain correct
measured values:
- 1 minute for fresh air calibration of the sensors
- 2 minutes for stable measured values at the instrument
Hint
To obtain accurate measurement values it’s important to re-calibrate the
instrument after each measurement (at the latest after one hour)!
To calibrate the sensors, proceed as follows:
- Switch off the instrument and wait for the switch off phase
- Switch on the device and refer to chapter "2. Measurement Preparations".
The current measured values of the active sensors are displayed in the measurement menu.
In addition, various measuring procedures are available:
Display Meaning Comment
Gas analysis 1 Display of 4 definable measured values Select the measured values with the <F4>
key
Gas analysis 2 Display of 4 definable measured values Select the measured values with the <F4>
key
Gas analysis 3 Display of 8 definable measured values Select the measured values with the <F4>
key
CO measurement Display of 4 measured values for testing CO with O2 reference Gas path check
O2 Check
Display of 3 measured values for testing the O2 in combustion air Set the zero point of the pressure sensor
with the <F4> key
Draught
measurement
Display of the measured value Draught / Pressure and storing a
reference value
While this measurement procedure is
active, the gas pump remains inactive
Set the zero point of the pressure sensor
with the <F4> key
Storing a reference value with <save>
Flow measurement
Display of 3 measured values for testing the flow inside an exhaust
pipe
Set the zero point of the pressure sensor
with the <F4> key
Enter the cross-section in the exhaust pipe
with the <F1> key
Hint
For a detailed description of the individual measuring procedures, see the
following sections.
