Ecom EN3 - Data Connection to PC; Data Recording with PC Software Ecom-DAS

Page 58 ecom-EN3
10.3 Data connection to PC
If the device is connected to a PC, measured values and plant data can be synchronized with
a PC software from ecom.
The following software solutions are available:
- ecom-DAS NT 2 (10.3.1)
- ecom-DAS 5(10.3.2)
- PC software (10.3.3)
10.3.1 Data recording with PC Software ecom-DAS NT 2
In addition to data logger recordings the data could also be transferred online via USB or AUX
to the software "ecom-DAS NT 2".
The following interfaces can be used for communication with the software:
- USB
- AUX = RS232
Hint
A driver is required to communicate with the PC software DAS NT 2 via the USB
interface.
 To download and install the necessary USB driver, see
https://www.ecom.de/en/downloads/
Hint
The transmission speed and the protocol are pre-defined for the smooth
communication of the instrument with the PC software DAS NT 2 via USB
interface.
 To enable communication with the PC software DAS NT 2, the
following settings must be made in the menu Adjustments / Internal /
USB:
Parameter Meaning Adjustment
Required setting
for DAS NT 2
Transfer speed 1200 … 115200 Baud 1200 Baud
Protocol
DAS = DAS NT 2
Enhanced = DAS 5
---- = no protocol
DAS
Hint
For further information on importing from the PC software and exporting to the
PC software, please refer to the operating instructions of the corresponding PC
software.
