Ecom EN3 - Pressure Tests (option)

Page 42 ecom-EN3
6.5 Pressure Tests (option)
Air pump
Safety valve
Conic test stopple, One-pipe
counter cap or High-pressure
test stopple
Connection hose
(ecom-EN3 / UNO -
Cross piece)
ecom-UNO (only for Loading
and Tightness Test)
ecom-EN3
Cross piece
Electrical connection
ecom-EN3 / UNO
Connection ecom-UNO
(+)
Syringe
Connection hose
(Pump - Cross piece)
Connection hose (Gas
system - Cross piece)
Connection ecom-
EN3 (delta p-)
Connection Squirt or Soot
pump
WARNING
1.
2.
Use only air or inert gas for check!
Respect the „Technical Rules for Gas installations“!
1
2
3
4
5
6
8
9
10
11
12
13
1 2
3
4 5
6
7
8
9
10
11
12
7
14
13
14
