Page 62
ecom-EN3
10.5 Data recording with Apps via BLE
To display and storage of measured values, the Apps "ecom connect BLE" and
“ecomMANDER” for smartphones are available.
The following operating systems are supported by the Apps:
- iOS
- Android
If the instrument is connected to the App via Bluetooth (BLE), the current measured values of
the instrument can be displayed directly in the App.
The measured values can be saved and exported together with the customer information to
be entered. These exported data can be sent for example by e-mail.
The following file formats can be exported:
- *.pdf
- *.csv
Hint
For the smooth communication of the instrument with the Apps via Bluetooth
(BLE), setting parameters are predefined.
To enable communication with the Apps, the following settings
are fixed in the Adjustments / Internal / Bluetooth menu:
Parameter Meaning Adjustment
Required setting
for ecom connect
Transfer speed
115200 Baud
Protocol
Enhanced
