Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.108 - 09/11/2021
CODE
DESCRIPTION
CEL9514-E
50 kgOIL
LOAD CELL
AMP MODU MTE
CONNECTION
CND0005
CONDENSER FAN 12 VDC
120X120X38
CNT4003-SP
12 lt BOTTLE
M1/4” SAE HFO-R134a
TARA 6000g.
CRP1240S
SPACER
BOTTLE SCALE
PLATE 4MM
CRP3939
SPACER
BOTTLE SCALE
PLATE 10 MM
ELT1171
BIG COIL ODE BDA
12V.FASTON CONNECTION
ELT3200-01
SHUKO
POWER WIRE
ELT3321
POLY-SNAP
