TEST I/O
From CALIBRATION, select TEST I/O, the following screen is displayed:
Activate the solenoid valve, one at a time; check the excitation of the valve directly on the
machine. Activate the compressor and the vacuum pump individually, checking the operation
of both.
Attention the compressor must be activated with caution, it must be switched on for at
least 10 seconds, it must not be switched off and on again immediately, if switched off,
wait at least 10 seconds before switching it on again.
Never activate EV4 and vacuum pump with pressures above 0.2 bar.
Before going out, check that all the solenoid valves, the compressor and the pump are
deactivated
Press ESC for exit, the CALIBRATION menu will be displayed
Tank Cell 0
Tank Temperature 0
AC Pressure 0
To Next Page
