Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.25 - 09/11/2021
BASIC COMPONENTS
Refer to Fig.7, Fig.8, Fig.9, Fig.10, Fig.11:
a) USB port
b) Printer cap
c) Main switch
d) Fuse (8A 230v;16A 100-110v)
e) Socket for electrical supply plug
f) Printer*
g) Printer flange*
h) Ventilation grid
i) Purge valve
j) Oil cartridge
k) Front plastic cover (option)
l) Tank scale
m) Condenser
n) swirling wheel
o) Manifold
p) control panel
q) Tank pressure gauge
r) Oil pump filling cap
s) Refrigerant tank lock bolt
t) Evaporator
u) New oil container
v) Used oil container
w) Refrigerant tank
x) Fan
y) 12V Power supply
z) Dryer filter
1) Vacuum pump
2) Compressor
3) LP manual valve
4) HP manual valve
5) LP service hose connection
6) HP service hose connection
7) Handle
8) Oil separator
9) Motherboard
(*) if installed, depending on machine model
