DISPLAY ICONS
ICON
DESCRIPTION
FUNCTION
AUTOMATIC
PROCEDURE
activates a menu that helps the user set up an automatic
recover/vacuum/leak test/charge sequence.
MANUAL
PROCEDURE
activates a menu that helps the user to perform a
manual operation:
STANDARD
RECOVERY
activates a menu that helps the user to perform a
recovery/recycling phase (without SAE J-2788 or SAE
J-2843 compliance)
VACUUM
activates a menu that helps the user to perform a
vacuum phase
OIL INJECTION
activates a menu that helps the user to perform a oil
injection followed by a gas filling phase
GAS CHARGE
activates a menu that helps the user to perform a gas
CHARGE phase
SETUP
activates the setup menu of the service station
MAINTENANCE
activates the maintenance menu of the service station
DATA
activates a menu that contains all the information of the
service station
ENTER
Enter symbol, to confirm
BACK
Back symbol, to return back without confirm
STOP
Stop symbol, to stop a phase
PRINT
Print symbol, to print data
ARROW
Arrow symbol, to move in the menu
OIL INJECTION
VACUUM
RECOVERY/RECYCLE
CHARGE
ESC
STOP
ENTER
