Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.112 - 09/11/2021
CODE
DESCRIPTION
RAC5150
R134a LP
CONNECTOR WITH
DEPRESSOR
RAC5155
DEPRESSOR VALVE
for RAC5149
and RAC5159
RAC5156
DEPRESSOR VALVE
RAC5805
NIPPLES
M1/4" M1/4” SAE
RAC5810
NIPPLES
M1/8" M1/4” SAE
RAC5865
"T" CONNECTION
3x1/4" SAE
RAC5917
TAP WITH FLANGE
1/4 SAE -1/2 ACME
HP-LP
RAC5998
DOUBLE REVOLVING
PIPE UNION
F-F1/4’’ SAE
