The data, information and descriptions, and the technology described herein are the exclusive intellectual property of Snap-on Climate Solutions S.r.l. and
constitute industrial secrets. Said information is communicated in strict confidentiality; said information may be used only for the purpose for which it is
communicated; said information may not be divulged, communicated, or revealed to third parties and/or reproduced by any means for any reason whatsoever; said
information is protected under applicable Italian competition and industrial property law.
Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.130 - 09/11/2021
MOTHERBOARD NEVO 2
[SCH1603]
rev.0
REF.
PIN
DESCRIPTION
BT1
Battery
BZ1
Buzzer
J3
TFT display
J4
DC - Input
J5
Printer (optional)
J6
USB port
J8
- - -
J9
- - -
J10
A/C pressure transducer
J11
Refrigerant tank+oil load cell - 50 kg
J12
- - -
J13
- - -
J14
- - -
J15
High pressure switch
J16
- - -
J17
Refrigerant tank temperature probe
J18
A/C pressure switch
J19
- - -
J20
- - -
J21
Tachymetric fan
J22 1-11
- - -
2-12
EV4
3-13
- - -
4-14
EV3
5-15
EV8
6-16
EV6
7-17
EV7
8-18
EV12
9-19
- - -
10-20
- - -
J23
Compressor
J24
Condenser
J25
Vacuum pump
J26
- - -
J28
- - -
J29
- - -
J30
- - -
J31
Input AC 230V
