Service manual Cinquecento12 (VA21) [MANUY2V.SB0] ed.1 ver.0.1.doc pag.136 - 09/11/2021
PIPING
REF.
DESCRIPTION
Code
T1
LP manual valve-Manifold
TUBK100
T2
HP manual valve-Manifold
TUBK100
T3
EV3-Evaporator inlet
TUBK030
T4
Evaporator outlet-Filter
TUBK045
T5
Evaporator heater-Condenser
TUBK060
T7
CV2-Evaporator heater
TUBK030
T8
EV4-Vacuum pump
TUBK085
T9
Compressor-Oil separator
TUBK060
T10
CV1-Compressor
TUBK100
Tb
Condenser-Refrigerant bottle (LP side)
TUB1174
Tr
Refrigerant bottle (HP side)-Manifold
TUB1175
Tuo
Manifold-used oil container
TUB1250
Ton
New oil container- EV12
TUB1250
Coc
Oil separator-EV6 Compressor
TUB1000.01
Clp
LP Manual valve-LP manometer
TUB1210.01
Chp
HP Manual valve-HP manometer
TUB1210.01
Csv
Refrigerant bottle-Purge valve
TUB1211
ELECTRONIC VALVES
REF.
DESCRIPTION
Code
3
EV3 Recovery valve
ELT1171 + VLV1170
4
EV4 Inlet vacuum electronic valve
ELT1171 + VLV1170
6
EV6 Oil compressor refill electronic valve
VLV1575
7
EV7 Oil discharge electronic valve
VLV1575
8
EV8 Refilling electronic valve
ELT1175 + VLV1175
12
EV12 new oil electronic valve
ELT1175 + VLV1175
ITEMS
REF.
DESCRIPTION
Code
7
A/C pressure switch
PRS4175-D
9
Evaporator
AKDIS003
15
Oil separator
AKDIS002
16
Safety Pressure switch (20 bar)
PRS4325-D
