ECTIVE CSI Series User Manual

34 ECTIVE CSI & SSI Series
Reccomended battery cables and battery capacity
(Cables and batteries are not included!)
Model
Input voltage
Number of sets Reccomended thickness at 100cm Reccomended thickness at 150cm Reccomended thickness at 200cm Reccomended thickness at 300cm Battery capacity
CSI 3 12 V 1 4 mm² 6 mm² 10 mm² 16 mm² >= 50 Ah
CSI 3 24 V 1 2,5 mm² 4 mm² 6 mm² 10 mm² >= 25 Ah
CSI 5 12 V 1 6 mm² 10 mm² 16 mm² 25 mm² >= 100 Ah
CSI 5 24 V 1 4 mm² 6 mm² 10 mm² 16 mm² >= 50 Ah
CSI / SSI 10 12 V 1 16 mm² 25 mm² 35 mm² 50 mm² >= 160 Ah
CSI / SSI 10 24 V 1 6 mm² 10 mm² 16 mm² 25 mm² >= 80 Ah
CSI / SSI 15 12 V 2 10 mm² 16 mm² 25 mm² 35 mm² >= 250 Ah
CSI / SSI 15 24 V 2 6 mm² 10 mm² 16 mm² 25 mm² >= 120 Ah
CSI / SSI 20 12 V 2 16 mm² 25 mm² 35 mm² 50 mm² >= 320 Ah
CSI / SSI 20 24 V 2 10 mm² 16 mm² 25 mm² 35 mm² >= 160 Ah
CSI / SSI 25 12 V 2 25 mm² 35 mm² 50 mm² 50 mm² >= 400 Ah
CSI / SSI 25 24 V 2 10 mm² 16 mm² 25 mm² 35 mm² >= 200 Ah
CSI / SSI 30 12 V 2 25 mm² 35 mm² 50 mm² 50 mm² >= 480 Ah
CSI / SSI 30 24 V 2 10 mm² 16 mm² 25 mm² 35 mm² >= 240 Ah
Caution!
Please note the capacity!
An underrun of the recommended battery capacity can cause a loss of performance or
serious use restrictions as a result of voltage drops.

ECTIVE CSI Series Specifications

General

Brand	ECTIVE
Model	CSI Series
Category	Inverter
Language	English
