ECTIVE CSI Series User Manual

50 ECTIVE CSI & SSI Series
Te chni cal in f orma tio n
CSI-Series
Model Power
Dimensions
(LxWxH)
Empty weight
CSI 3 300 W 270 x 150 x 55 mm 2,1kg
CSI 5 500 W 355 x 150 x 55 mm 3,0kg
CSI 10 1000 W 430 x 150 x 75 mm 3,7kg
CSI 15 1500 W 450 x 220 x 90 mm 5,3kg
CSI 20 2000 W 480 x 220 x 90 mm 6,5kg
CSI 25 2500 W 530 x 220 x 90 mm 7,3kg
CSI 30 3000 W 480 x 220 x 150 mm 9,5kg
SSI-Series
Model Power
Dimensions
(LxWxH)
Empty weight
SSI 10 1000 W 380 x 220 x 150 mm 5,5kg
SSI 15 1500 W 450 x 220 x 150 mm 6,5kg
SSI 20 2000 W 500 x 220 x 150 mm 8,5kg
SSI 25 2500 W 520 x 220 x 150 mm 9,0kg
SSI 30 3000 W 500 x 220 x 150 mm 10,5kg

ECTIVE CSI Series Specifications

General

Waveform	Pure Sine Wave
Efficiency	>90%
USB Output	5V/2.1A
Input Voltage	12V / 24V
Protection Features	Overload, Short Circuit, Over Temperature
Operating Temperature	-20°C - +50°C
Dimensions	Varies by model
Weight	Varies by model
Cooling	Fan Cooling
