38 ECTIVE CSI & SSI Series
Overview of the inverter
These illustrations show the most important external components and connections.
Front view: CSI 3
1. Switch ON/OFF
2. LED „Fault“
3. USB-port
4. Protective earthing
5. Shore power
6. LED „Inverter
7. LED „AC-Charge
8. 230 V power socket
Front view: CSI 5 and CSI 10
1. Switch ECO/OFF/UPS
2. LED „Power
3. LED „Fault“
4. LED „Charge
5. LED „AC-In
6. LED „By-Pass“
7. Remote control port
8. USB-port
9. Shore power
10. Fuse
11. Protective earthing
12. 230 V power socket
3 4
5
2
1
1
9
3 4
10
6 7
7 8
2
5
6
11
8
12
