ECTIVE CSI Series User Manual

44 ECTIVE CSI & SSI Series
Power of the AC-charger CSI-Series
Model Charging Current
24 V-Models: CSI 3, CSI 5, CSI 10 5A
24 V-Models: CSI 15, CSI 20, CSI 25, CSI 30
12V-Models: CSI 3, CSI 5, CSI 10
10A
12 V-Models: CSI 15, CSI 20, CSI 25, CSI 30 20A
Power of the AC-charger SSI-Series
Model Charging Current
All 24V-Models (SSI 10, SSI 15, SSI 20, SSI 25, SSI 30) 10A
All 12V-Models (SSI 10, SSI 15, SSI 20, SSI 25, SSI 30) 20A
Efficiency range*
System voltage CSI-Series SSI-Series
12V 86% – 90% 88% – 92%
24V 87% – 91% 89% – 93%
* The efficiencies depend on the type of consumer and load.
For example, the inverter typically has the highest efficiency at a load of approx. 70 %.
Operating performance MPPT-charge controller (SSI 10 - SSI 30)
Battery voltage 12V 24V
Charge efficiency > 97%
Solar input voltage 15 – 70V 24 – 70V
Max. input current 20 A 20 A
Max. input power 550 W

ECTIVE CSI Series Specifications

General

Waveform	Pure Sine Wave
Efficiency	>90%
USB Output	5V/2.1A
Input Voltage	12V / 24V
Protection Features	Overload, Short Circuit, Over Temperature
Operating Temperature	-20°C - +50°C
Dimensions	Varies by model
Weight	Varies by model
Cooling	Fan Cooling
