ECTIVE CSI Series User Manual

ECTIVE CSI & SSI Series 41
Front view: SSI 10 to SSI 30
1. Switch ECO/OFF/UPS
2. LED „Power“
3. LED „Solar“
4. LED „Fault“
5. LED „Charge“
6. LED „AC-In“
7. LED „By-Pass“
8. Remote control port
9. USB-port
10. Shore power
11. Protective earthing
12. MC4 Solar
Connection
13. 230 V power socket
9
8
4
1
5
6
7
10
12
3
2
11
+ -
13

ECTIVE CSI Series Specifications

General

Waveform	Pure Sine Wave
Efficiency	>90%
USB Output	5V/2.1A
Input Voltage	12V / 24V
Protection Features	Overload, Short Circuit, Over Temperature
Operating Temperature	-20°C - +50°C
Dimensions	Varies by model
Weight	Varies by model
Cooling	Fan Cooling
