Chapter 5
| Port Connections
How to Connect to SFP Fiber Optic Ports
– 40 –
Note:
Be sure to secure cables properly and route them away from the switch
without exceeding the minimum bending radius for fiber cables (typically a few
inches). Use cable ties to bundle cables together and secure coiled loops of excess
cable. Do not let cables hang free supporting their own weight or pull in any way
that puts stress on the connectors.
Note:
For the combination ports, software settings can be set to give priority to
either the SFP slot or RJ-45 port. Verify that the corresponding shared RJ-45 port
does not have the priority in the software settings. Otherwise if the RJ-45 port has
the priority and a valid connection is made to the RJ-45 port, the corresponding
shared SFP slot will be disabled.
