– 15 –
3 Switch Chassis
This chapter includes these sections:
◆ “Rack Mount Guidelines” on page 15
◆ “Switch Cooling Requirements” on page 16
◆ “How to Install the Switch in a Rack” on page 17
◆ “How to Install the Switch on a Desktop or Shelf” on page 18
◆ “How to Install an SFP Transceiver” on page 19
Rack Mount Guidelines
When rack mounting the switch, pay particular attention to the following factors:
◆
Rack Types:
You can use any standard EIA 19-inch equipment rack with either
two or four posts. The bracket hole pattern should be spaced 1U (1.75 in. or
4.45 cm) apart.
◆
Rack Stability:
Whenever possible, secure the rack to the building ceiling or
floor, particularly if you are located in a region where earthquakes are common.
◆
Rack Planning:
When installing equipment in a rack, first plan how units can
be best arranged. Try to always mount the heaviest equipment at the bottom
of the rack.
◆
Temperature:
Since the temperature within a rack assembly may be higher
than the ambient room temperature, check that the rack-environment
temperature is within the specified operating temperature range. See “Switch
Cooling Requirements” on page 16.
◆
Mechanical Loading:
Do not place any equipment on top of a rack-mounted
unit.
◆
Circuit Overloading:
Be sure that the supply circuit to the rack assembly is
not overloaded.
◆
Grounding:
Rack-mounted equipment should be properly grounded.
