Edge-Core ECS4110-28P - Figure 7: Inserting an SFP Transceiver into a Slot

Chapter 3 | Switch Chassis
How to Install an SFP Transceiver
– 20 –
Figure 7: Inserting an SFP Transceiver into a Slot
Note: To uninstall a transceiver: First disconnect the network cable, then pull the
tab to remove the transceiver from the slot.
SFP transceiver slot. SFP fiber transceiver.
1
2
1
2
