4 Power and Grounding
This chapter includes these sections:
◆ “About the Switch Power Supply” on page 21
◆ “How to Ground the Chassis” on page 22
◆ “How to Connect to AC Power” on page 23
About the Switch Power Supply
The switch requires power from an external AC power supply that can provide 100
to 240 VAC, 50-60 Hz. A standard AC power socket is located on the rear panel of
the switch. The power socket is for the AC power cord.
Figure 8: AC Power Supply Socket
Table 3: AC Power Supply Specifications
Item Description
AC Input 100-240 VAC, 50-60 Hz 6 A
Power Supply 100-240 VAC, 50-60 Hz, auto-sensing
Max. Power Consumption 100 VAC@50 Hz 450 W
