– 7 –
Figures
Figure 1: Front Panel 9
Figure 2: Rear Panel 10
Figure 3: Switch Cooling 16
Figure 4: Attaching the Brackets 17
Figure 5: Installing the Switch in a Rack 18
Figure 6: Attaching the Adhesive Feet 18
Figure 7: Inserting an SFP Transceiver into a Slot 20
Figure 8: AC Power Supply Socket 21
Figure 9: Grounding Terminal 22
Figure 10: AC Power Cord and Power Socket 23
Figure 11: System and Port Status LEDs 25
Figure 12: Console Port 26
Figure 13: Console Port Connection 27
Figure 14: Reset Button 29
Figure 15: RJ-45 Connector 32
Figure 16: Making Twisted-Pair Connections 35
Figure 17: Making a Connection to an SFP Port 36
