Chapter 24
| Multicast Filtering Commands
MVR for IPv4
– 746 –
Example
The following shows MVR protocol-related statistics received:
Console#show mvr domain 1 statistics input
MVR Domain : 1 , MVR VLAN: 2
Input Statistics:
Interface Report Leave G Query G(-S)-S Query Drop Join Succ Group
--------- -------- -------- -------- ------------- -------- --------- ------
Eth 1/ 1 23 11 4 10 5 20 9
Eth 1/ 2 12 15 8 3 5 19 4
DVLAN 1 2 0 0 2 2 20 9
MVLAN 1 2 0 0 2 2 20 9
Console#
The following shows MVR protocol-related statistics sent:
Console#show mvr domain 1 statistics output
MVR Domain : 1 , MVR VLAN: 2
Output Statistics:
Interface Report Leave G Query G(-S)-S Query Drop Group
---------- -------- -------- -------- ------------- -------- ------
Eth 1/ 1 12 0 1 0 0 0
Eth 1/ 1 12 0 1 0 0 0
Eth 1/ 2 5 1 4 1 0 0
DVLAN 1 7 2 3 0 0 0
MVLAN 1 7 2 3 0 0 0
Console#
Table 141: show mvr statistics input - display description
Field Description
Interface Shows interfaces attached to the MVR.
Report The number of IGMP membership reports received on this interface.
Leave The number of leave messages received on this interface.
G Query The number of general query messages received on this interface.
G(-S)-S Query The number of group specific or group-and-source specific query
messages received on this interface.
Drop The number of times a report, leave or query was dropped. Packets may
be dropped due to invalid format, rate limiting, packet content not
allowed, or MVR group report received
Join Succ The number of times a multicast group was successfully joined.
Group The number of MVR groups active on this interface.
Table 142: show mvr statistics output - display description
Field Description
Interface Shows interfaces attached to the MVR.
Report The number of IGMP membership reports sent from this interface.
