Chapter 24
| Multicast Filtering Commands
MVR for IPv6
– 762 –
Example
The following shows the MVR6 settings:
Console#show mvr6
MVR6 802.1p Forwarding Priority: Disabled
MVR6 Proxy Switching : Enabled
MVR6 Robustness Value : 1
MVR6 Proxy Query Interval : 125(sec.)
MVR6 Source Port Mode : Always Forward
Domain : 1
MVR6 Config Status : Enabled
MVR6 Running Status : Active
MVR6 Multicast VLAN : 1
MVR6 Current Learned Groups : 0
MVR6 Upstream Source IP : FF05::25
.
.
.
Table 146: show mvr6 - display description
Field Description
MVR6 802.1p
Forwarding Priority
Priority assigned to multicast traffic forwarded into the MVR6 VLAN
MVR6 Proxy Switching Shows if MVR proxy switching is enabled
MVR6 Robustness Value Shows the number of reports or query messages sent when proxy
switching is enabled
MVR6 Proxy Query
Interval
The interval at which the receiver port sends out general queries
MVR6 Source Port Mode Shows if the switch only forwards multicast streams which the source port
has dynamically joined or always forwards multicast streams
Domain An independent multicast domain.
MVR6 Config Status Shows if MVR is globally enabled on the switch.
MVR6 Running Status Indicates whether or not all necessary conditions in the MVR environment
are satisfied. (Running status is true as long as MVR Status is enabled, and
the specified MVR VLAN exists, and a source port with a valid link has been
configured (using the mvr6 type command.)
MVR6 Multicast VLAN Shows the VLAN used to transport all MVR multicast traffic.
MVR Current Learned
Groups
The current number of MVR group addresses
MVR6 Upstream Source
IP
The source IP address assigned to all upstream control packets.
