Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 463 –
Trunk Status Display Commands
show lacp This command displays LACP information.
Syntax
show lacp [port-channel] {counters | internal | neighbors | sysid}
port-channel - Local identifier for a link aggregation group. (Range: 1-16)
counters - Statistics for LACP protocol messages.
internal - Configuration settings and operational state for local side.
neighbors - Configuration settings and operational state for remote side.
sysid - Summary of system priority and MAC address for all channel groups.
Default Setting
Port Channel: all
Command Mode
Privileged Exec
Example
Console#show lacp 1 counters
Port Channel : 1
------------------------------------------------------------
Member Port : Eth 1/23
LACPDU Sent : 10
LACPDU Received : 5
MarkerPDU Sent : 0
MarkerPDU Received : 0
MarkerResponsePDU Sent : 0
MarkerResponsePDU Received : 0
Unknown Packet Received : 0
Illegal Packet Received : 0
.
.
.
Table 77: show lacp counters - display description
Field Description
LACPDU Sent Number of valid LACPDUs transmitted from this channel group.
LACPDU Received Number of valid LACPDUs received on this channel group.
MarkerPDU Sent Number of valid Marker PDUs transmitted from this channel group.
MarkerPDU Received Number of valid Marker PDUs received by this channel group.
MarkerResponsePDU
Sent
Number of valid MarkerResponse PDUs transmitted from this channel group.
MarkerResponsePDU
Received
Number of valid MarkerResponse PDUs received by this channel group.
