Chapter 24
| Multicast Filtering Commands
MVR for IPv4
– 727 –
Default Setting
None
Command Mode
Privileged Exec
Command Usage
Using this command without specifying an interface displays information for all
interfaces.
Example
Console#show ipv6 mld throttle interface ethernet 1/3
Eth 1/3 Information
Status : TRUE
Action : Replace
Max Multicast Groups : 10
Current Multicast Groups : 0
Console#
MVR for IPv4
This section describes commands used to configure Multicast VLAN Registration for
IPv4 (MVR). A single network-wide VLAN can be used to transmit multicast traffic
(such as television channels) across a service provider’s network. Any multicast
traffic entering an MVR VLAN is sent to all subscribers. This can significantly reduce
to processing overhead required to dynamically monitor and establish the
distribution tree for a normal multicast VLAN. Also note that MVR maintains the
user isolation and data security provided by VLAN segregation by passing only
multicast traffic into other VLANs to which the subscribers belong.
Table 137: Multicast VLAN Registration for IPv4 Commands
Command Function Mode
mvr Globally enables MVR GC
mvr associated-profile Binds the MVR group addresses specified in a profile to an
MVR domain
GC
mvr domain Enables MVR for a specific domain GC
mvr priority Assigns a priority to all multicast traffic in the MVR VLAN GC
mvr profile Maps a range of MVR group addresses to a profile GC
mvr proxy-query-interval Configures the interval at which the receiver port sends out
general queries.
GC
mvr proxy-switching Enables MVR proxy switching, where the source port acts
as a host, and the receiver port acts as an MVR router with
querier service enabled
GC
