Chapter 24
| Multicast Filtering Commands
MLD Snooping
– 718 –
Table 135: show ipv6 MLD snooping statistics summary - display description
Field Description
Number of Groups Number of active MLD groups active on the specified interface.
Physical Interface (Port/Trunk)
Querier:
Transmit
General
The number of general queries sent from this interface.
Group Specific
The number of group specific queries sent from this interface.
Recieved
General
The number of general queries received on this interface.
Group Specific
The number of group specific queries received on this interface.
Report & Leave
Transmit
Report
The number of MLD membership reports sent from this interface.
Leave
The number of leave messages sent from this interface.
Recieved
Report
The number of MLD membership reports received on this interface.
Leave
The number of leave messages received on this interface.
join Success
The number of times a multicast group was successfully joined.
Filter Drop
The number of messages dropped by an MLD filtering profile.
Source Port Drop
The number of dropped messages that are received on MVR source
port or mrouter port.
Others Drop
The number of received invalid messages.
Logical Interface (VLAN) The following additional parameters are included for a VLAN interface
Querier:
Other Querier IPv6 address of remote querier on this interface.
Other Uptime Time remote querier has been up.
Other Expire Time after which remote querier is assumed to have expired.
Self Addr IPv6 address of local querier on this interface.
Self Expire Time after which local querier is assumed to have expired.
Self Uptime Time local querier has been up.
Report & Leave
Host Addr The link-local or global IPv6 address that is assigned on that VLAN.
Unsolicit Expire The number of group leaves resulting from timeouts instead of explicit
leave messages.
