Chapter 1
| Initial Switch Configuration
Connecting to the Switch
ā 66 ā
ā Filter packets using Access Control Lists (ACLs)
ā Configure up to 4094 IEEE 802.1Q VLANs
ā Enable GVRP automatic VLAN registration
ā Configure IP routing for unicast or multicast traffic
ā Configure router redundancy
ā Configure IGMP multicast filtering
ā Upload and download system firmware or configuration files via HTTP (using
the web interface) or FTP/TFTP (using the command line or web interface)
ā Configure Spanning Tree parameters
ā Configure Class of Service (CoS) priority queuing
ā Configure static or LACP trunks (up to 16)
ā Enable port mirroring
ā Set storm control on any port for excessive broadcast, multicast, or unknown
unicast traffic
ā Display system information and statistics
ā Configure any stack unit through the same IP address
Connecting to the
Console Port
The switch provides an RS-232 serial port that enables a connection to a PC or
terminal for monitoring and configuring the switch. A null-modem console cable is
provided with the switch.
Note:
When configuring a stack, connect to the console port on the Master unit.
Attach a VT100-compatible terminal, or a PC running a terminal emulation program
to the switch. You can use the console cable provided with this package, or use a
null-modem cable that complies with the wiring assignments shown in the
Installation Guide.
To connect a terminal to the console port, complete the following steps:
1. Connect the console cable to the serial port on a terminal, or a PC running
terminal emulation software, and tighten the captive retaining screws on the
DB-9 connector.
2. Connect the other end of the cable to the RS-45 serial port on the switch.
3. Make sure the terminal emulation software is set as follows:
ā
Select the appropriate serial port (COM port 1 or COM port 2).
ā
Set the baud rate to 115200 bps.
ā
Set the data format to 8 data bits, 1 stop bit, and no parity.
