GS-60B Residential Gas Meter - Product Guide
Copyright © 2020 EDMI Europe Ltd. All rights reserved
Version / Status: 1.0
Public
PAGE 26 OF 46
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
11.5.10.3 Signal Strength
Displays the Received Signal Strength Indicator, which displays the link quality of received ZigBee
packets, in units of dBm.
When entered, this menu screen displays:
The meter samples the RSSI for three seconds and then displays the signal strength. For example:
When in this menu, the UI buttons perform the following functions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
11.5.10.4 Comms
The Comms menu displays the time and date last successful communication from the meter to the
selected device. The screen does not refresh the timestamp until the screen is dismissed and
refreshed.
For example:
When in this menu, the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
S
i
g
n
a
l
S
t
r
e
n
g
t
h
C
h
e
c
k
i
n
g
.
.
.
S
i
g
n
a
l
S
t
r
e
n
g
t
h
-
5
6
d
B
m
L
a
s
t
C
o
m
m
s
2
9
/
0
6
/
1
5
1
6
:
4
5
