Edwards iXM Series User Manual

Warning message on PDT Acon message on PD
T
Warning 55.13 - Sensor Fault on page 71 Check DP thermistor
Warning 56.11 - Exh Temp High on page 72 Check Exhaust Temperature
Warning 56.13 - Sensor Missing on page 72 Check Exhaust Thermocouple
Warning 56.13 - Sensor Fault on page 72 Check Exhaust Thermocouple
Warning 57.11 - DP Mtr Temp High on page 72 Check Cooling
Warning 57.13 - Sensor missing on page 72 Check DP Mtr Thermistor
Warning 57.13 - Sensor Fault on page 72 Check DP Mtr Thermistor
Warning 63.11 - DP Temp High on page 72 Check Cooling
Warning 63.13 - Sensor missing on page 72 Check DP Thermistor
Warning 63.13 - Sensor Fault on page 73 Check DP Thermistor
Warning 70.11 - DP E/C Temp High on page 73 Check Cooling
Warning 70.13 - Sensor missing on page 73 Check DP Thermistor
Warning 70.13 - Sensor Fault on page 73 Check DP Thermistor
Warning 71.13 - AC Sup Missing on page 73 Check Acc Module
Warning 84.11 - Exh Temp High on page 73 Check Exh Pipe Temperature
Warning 84.13 - Sensor missing on page 73 Check Exh Pipe Thermistor
Warning 84.13 - Sensor Fault on page 73 Check Exh Pipe Thermistor
Warning 152.01 - Valve Not Shut on page 74* Check Gate Valve
Warning 153.01 - Valve Not Open on page 74* Check Ga
te Valve
Warning 161.01 - GV Missing on page 74 Check Gate Valve
Warning 161.01 - GV Fault on page 74 Check Gate Valve
Warning 176.01 - MB zzzzzzzzzzzzz on page 74
xxxx yyyy
Diag aaaa bbbb
Warning 176.13 - No MB Inv Comms on page 74 See manual
Warning 186.01 - DP zzzzzzzzzzzzz on page 74
xxxx yyyy
Diag aaaa bbbb
Warning 186.13 - No DP Inv Comms on page 74 See manual
Warning 190.01 - Valve Missing on page 75 Check DP Stator Valve
Warning 190.01 - Valve Fault on page 75 Check DP Stator Valve
Warning 191.01 - Valve Missing on page 75 Check DP Motor Valve
Warning 191.01 - Valve Fault on page 75 Check DP Motor Valve
Warning 192.01 - Valve Missing on page 75 Check DP EC Valve
Warning 192.01 - Valve Fault on page 75 Check DP EC Valve
Warning 193.01 - Valve Missing on page 75 Check MB STATOR Valve
Warning 193.01 - Valve Fault on page
75 Check MB STATOR Valve
* This warning will only clear when the valve has successfully been opened and closed
Note:
Some of these warnings apply to pump sensors that are only presen
t on certain dry
pumping system variants.
10/2020 - ©Edwards Limited
Page 69M56635880_D
M56635880_D - Fault nding
