Figure 20 nES750 Dimensions
A. Inlet port B. Exhaust port
C. Oil level switch D. Motor connecon
E. External ltraon connecon
A. Inlet port B. Exhaust port
C. Oil level switch D. Motor connecon
E. External ltraon connecon
4.2 Installaon guidelines
▪
Use the list as a guide for the installaon of the vacuum pump. The list is not
exhausve. Every vacuum pump installaon is unique, and care must be used in
the placement of each pump. If you are not sure of any installaon variable,
contact us.
▪
For bare-sha nES pumps supplied without a motor, the installaon of a three-
phase electric motor is mandatory before use. Follow the installaon procedure
provided with the pump. Bare-sha pumps are delivered either with an IEC or a
NEMA motor coupling element. Use a motor with the power and frame size that
matches the following specicaon:
Pump
size
NEMA motor
frame size
NEMA motor
power 60 Hz
IEC motor frame size
(as per IEC60072-1)
IEC motor power
50 Hz/60 Hz
nES40 145TC 2 HP n/a n/a
nES65 145TC 3 HP 100 L (B34/FT130) 2.2/3.0 kW
nES100 184TCH 5 HP 100 L (B14/FT130) 3.0/3.6 kW
nES200 213TC 7.5 HP n/a n/a
nES300 215TC 10 HP 132 S (B14/FT165) 5.5/6.6 kW
