STP-301/451 Series Instruction Manual
2-2
Installation
(1) Rotor Blade
(2) Stator Blade
(3) Radial Sensor
(4) Radial Electromagnet
(6) Axial Electromagnet
(5) Axial Sensor
(8) Touch Down Bearing
(7) Touch Down Bearing
Figure 2.1 Cross Sectional View of the STP Pump
