STP-301/451 Series Instruction Manual
6-6
Installation
6.1.4 Side Panel (Left)
(24) Air Cooling Fan
z For cooling the inside of the STP control unit.
(24)
Figure 6.4 STP Control Unit Side Panel (Left)
