2.6 Label affixing positions
Refer to Section 1.6, "Labels" for the details of the labels 1 to 4.
1 STP pump installation warning label
2 Heavy product caution label
3 High voltage device caution label
4 Rotational direction instruction label
5 Name plate
6 Parts number
7 Notice label
Figure 9 - Label affixing positions
1
3
7
2
4
6
5
