Edwards STP-iS2207C

STP-iS2207 Series Turbomolecular Pump
MT-89E-001-C
Page 62
4
OPERATION
4.9.4 Output signal pins
Table 14 and Figure 33. The pins function when the input operation port is either in parallel port setting
or serial port setting.
Three abbreviations are used in Table 14.
N.O OUT: Normal Open Output Pin
N.C OUT: Normal Close Output Pin
COM: Common Pin
