27
7. REAR PANEL CONTINUITY OUTPUT TERMINAL (OPT.7002) : 2
nd
continuity output connector in
parallel with the front panel output.
8. CALIBRATION BUTTON: To put the instrument into the calibration mode push this button and
turn on the power switch simultaneously.
9. FUSE RECEPTACLE: To change the fuse, unplug the power (mains) cord and turn the fuse
receptacle counter-clockwise. The fuse compartment will be exposed. Please replace the fuse
with one of the proper rating.
10. INPUT POWER RECEPTACLE: Standard IEC 320 connector for connection to a standard NEMA
style line power (mains) cord.
11. CHASSIS GROUND (EARTH) CONNECTION: This terminal should be connected to a good earth
ground before operation.
12. SCANNER OUTPUTS (OPT.7004): Optional scanner matrix that provides 8 HV/Return
connections. Please refer to 4.6 Test Parameters.
13. REAR PANEL CURRENT TERMINAL: 2
nd
current output connector in parallel with the front
panel connector.
14. SCANNER OUTPUTS: Provides 8 HV/Return connections and 8 Ground Bond connections.
