EEC SE 7441 - Page 81

73
REMOTE FILE SELECT TRUTH TABLE
BIT 4
BIT 3
BIT 2
BIT 1
FILE #
0
0
0
1
01
0
0
1
0
02
0
0
1
1
03
0
1
0
0
04
0
1
0
1
05
0
1
1
0
06
0
1
1
1
07
1
0
0
0
08
1
0
0
1
09
1
0
1
0
10
1
0
1
1
11
1
1
0
0
12
1
1
0
1
13
1
1
1
0
14
1
1
1
1
15
1= Momentary Contact closure between BIT and COMMON
0= No Contact closure between BIT and COMMON
When you want to recall the file 3 that the signal of BIT4 to BIT1 are 0011.
ACTIVATING MEMORY PROGRAM FUNCTIONS THROUGH THE REMOTE
CONNECTOR, SELECTS THE PROGRAM AND STARTS THE TEST WHICH IS
PREPROGRAMMED INTO THAT MEMORY
ACTIVATION DES FONCTIONS DE MÉMOIRE PROGRAMME VIA LE CONNECTEUR REMOTE ,
SÉLECTIONNE LE PROGRAMME ET LANCE LE TEST QUI EST PRÉPROGRAMMÉ DANS CETTE
MÉMOIRE
DO NOT CONNECT VOLTAGE OR CURRENT TO THE SIGNAL INPUTS, THIS
COULD RESULT IN DAMAGE TO THE CONTROL CIRCUITRY.
NE PAS CONNECTER TENSION OU DE COURANT AUX ENTRÉES DE SIGNAL, CELA POURRAIT
PROVOQUER DES DOMMAGES AU CIRCUIT DE CONTRÔ LE
Remote Interlock
SE series is equipped with a Remote Interlock feature. Remote Interlock utilizes a set of closed
contacts to enable the instrument’s output. If the Remote Interlock contacts are open the output
of the instrument will be disabled. Remote Interlock could also be referred to as a remote system
lockout, utilizing “fail when open” logic. If the Remote Interlock contacts are open and the TEST
