89
0=None, 1=Int, 2=Ext 1,
3=Int+Ext 1,
4=Ext 2, 5=Int+Ext 2,
6=Ext 1+Ext 2,
7=Int+Ext 1+Ext 2
List Prompt by step number
List Step Parameters by step number
TD?
Read the active data being displayed on the LCD display while the test is in process. Will also read
the last data taken when the test sequence has completed. Each parameter is separated by
commas and includes step number, test type, test status, and metering. The syntax for this
command response is {step, test type, status, meter 1, meter 2, meter 3}. ACW test displays 4
meters. Each meter will contain only the value and not the units. In the case of DCW current
where both uA and mA are used on the display, the command response will always indicate the
current in uA for example 2.0mA will respond with 2000 for 2000uA.
RD <step number>?
Read the results for an individual step. The step number is the actual step number that has been
saved within the file, not the order of which the steps were executed. For example if the test was
executed starting from step 3 and ending with step 5 then the first step test results will be found
in location 3 not in location 1. Each parameter is separated by commas and includes step number,
test type, test status, and metering. The syntax for this command response is {step, test type,
status, meter 1,meter 2,meter 3}. ACW test displays 4 meters. Each meter will contain only the
value and not the units. In the case of DCW current where both uA and mA are used on the display
the command response will always indicate the current in uA for example 2.0mA will respond with
2000 for 2000uA.
RR?
Read the remote Reset input signal. When the remote reset has been activated by closing the
contacts the query will return a value of 1 to indicate the instrument is being Reset.
RI?
Read the remote Interlock input signal. When the remote Interlock has been activated by opening
the contacts the query will return a value of 0 to indicate the instrument is in the Interlock state
