12
Hang the special end cap in the cable housing holder of the seat post mounting inter-
face.
Attention! When installing in an aluminum frame with non-anodized
inner walls, lubricate the bushing tube with grease beforehand.
When installing in a carbon frame, never treat parts with rubbing
paste
Now carefully insert the seat post into the frame until the bushing tube slides into the
seat tube. Carefully press the outer sleeve onto the seat tube by hand until you feel the
outer sleeve stop.
Push the seat post down until the post pin mounting
interface of the seat post reaches the Pospin interface of
the frame. You can see this from the outside when you
look into the hole in the postpin interface of the frame. If
necessary, turn the seat post a little and slide it so that the
postpin axle can be inserted. Screw in the Postpin axle with
a 5mm Allen key and tighten it loosely
Push the outer sleeve and the bushing tube down for easier assembly. The cable must
remain tensioned throughout the insertion of the seat post into the seat tube of the fra-
me. It is best to hold the cable together with the cable housing at its end. Pull the cable
and the cable housing slightly during insertion so that it can slide through the frame.
