Eightpins H01 - Assembly of the Remote Lever

15
EIGHTPINS
Assembly of the remote lever
The cable system of the Eightpins seatpost consists of a common
cablehousingwithaSteelcoreandashort,moreexiblecable
housing with an Aluminum core directly at the remote lever. The
cable system right at the remote lever consists of a 10 cm Aluminum
cablehousing,aspeciccabletensionadjusetrandaspecicend
cap for the remote lever featuring a reduced outer diameter. The
specicendcapisinstalledattheoneendofthecablehousing,the
cable tension adjuster at the other end. The cable tension adjuster
is installed so that the side with the 4 mm label is connected with the
Aluminum cable housing. The second end is attached to the steel
cable housing that reaches out of the frame.
Note: Initially, put the cable tension adjuster into the minimum cable length position.
Install the remote lever between the grip and the brake lever and tighten its screw with 2.5 Nm.
Note: The lever can be used with 2-speed drivetrain gear levers and without. Make sure the Eight-
pins remote lever does not interfere with the gear lever. Further turn it upwards, in order to avoid this.
Beforethecableisattachedtotheremote,pullitrmlyuntilthedroppermechanicsisfullyopen.Thisprocessis
importanttoconrmthatallcomponentsofthecablesystemsittightly.
Seilzug Aussenhülle Seilzug
Seilzugeinsteller
Flex Aluminium-
Aussenhülle
Endkappe klein
Seilzugklemme
