Eightpins H01 - Remove Outer Sleeve and the Bushing Tube; Oil Lubrication of the Seatpost Tube

23
EIGHTPINS
Remove outer sleeve and the bushing tube:
Reinstall in reverse order
Oil lubrication of the seatpost tube
Fill Eightpins Fluid V3 oil carefully and very slowly into the grease nipple of the outer sleeve using using a 2.5 ml syringe.
Note!Rellamaximumof2.5mlofoilasotherwisetheinternalreservoirwilloverowandthe
oil will run into the frame.
Oil safetysheet: https://www.eightpins.at/service-einbau-h01/
Unscrew the fastening
screw of the outer casing
with a 3 mm Allen key.
Pull up the outer sleeve by
hand.
Pull the bushing tube out of
the seat tube.
