Cleaning the bushing tube
Note! The wall thickness of the tube is very thin..
Don‘t crush!
Roll up the felt ring inside
the outer sleeve so that it
rests on the groove.
Carefully press the felt ring
into the groove by hand.
Make sure that both ends
are fully pressed in after
joint and are not overlap-
ping or twisted.
Now reinsert the cleaned
or the new scraper into the
upper groove.
Tighten the sealing lip ring
over the wiper.
Carefully clean the sliding
sleeve tube with a damp
cloth.
