EIGHTPINS
Manual
Using the seatpost
In order to lower the seatpost, push the remote lever at the handlebar and push down the seatpost. In order to keep the new saddle position,
releasetheremotelever.Extendingtheseatpostagain,youneedtopushtheremoteleverandwithoutcounterforceletitnditsoriginalheight.The
Eightpins H01 seat post is locked or extended using a hydraulic gas spring. The lowering function works steplessly.
Attention: The remote lever must not be pushed if the bike hangs on the saddle.
Seat post alignment
The Eightpins H01 seat post is equipped with a tolerance compensation system. This enables a rotation of the seat post of ± 3 ° around the
longitudinal axis. If the saddle alignment is rotated around the longitudinal axis, the saddle can be aligned again by loosening the postpin axle and
tightening it again with 8Nm after alignment.
Height adjustment top position
See chapter height adjustment
Saddle tilt adjustment
See chapter saddle mounting
Before every trip
Before each ride, check the following functions on the seat post.
- Freedom of play rotation: The seat post should have only slight play in both directions of rotation. If there is more play, check whether the Postpin
thru axle is screwed tight with 8Nm.
- Clearance of seat post: The seat post tube should only have a maximum of 2-3mm play to the front and rear when tipping. If the play is greater,
check whether the minimum insertion depth has been reached and whether the slide sleeve tube is in order. (See service)
