Eightpins H01 - Installing the Bowden End Cap; Installing the Seatpost

11
EIGHTPINS
Installing the bowden end cap
Installing the seatpost
AspecialendcapisrequiredtoxtheoutercovertothewidemountinginterfaceoftheH01seatpost.Thespecial
end cap is only required in bicycles without e-drive (left image). Bicycles with electric drive have little space between
themotorandseatpostfortheexitofthecable.Aspecialexchainoutercableisusedhere(rightpicture).Thisis
installed between the outer shell and the special end cap.
Hook the cable head into the
actuation lever of the seat post
Insert the cable into the outer shell and push it almost
completely through the cable housing
Before installing the seat post, check whether the small tube and the washers for tole-
rance compensation of the seat post are installed.
