Eizo FlexScan EV2785 User Manual

2-3. Switching Display Modes (Color Modes)
This product is preinstalled with color modes for various display purposes.
Switch the mode according to the purpose and content for display. This allows the monitor to display
images in a manner appropriate to the display content.
●
Display Modes
Color Mode Purpose
User1
User2
Select either of these modes to set a user-dened display mode.
sRGB
This mode is suitable for matching color reproduction with peripheral devices that
support sRGB, such as when printing photos taken using a digital camera.
Paper
This mode uses color tones and contrast similar to that of paper to produce a printed
paper effect. It is suitable for displaying images from media such as books and
documents.
Movie
This mode displays moving images brightly and with a clear-cut three-dimensional
appearance. It is suitable for playing back video content.
DICOM
Select this mode to simply display medical purpose digital images based on DICOM
Part 14.
Attention
• This is not intended to be used for diagnostic purposes.
Note
• "Screen InStyle" allows you to select the color mode automatically according to the software in use.
• In Paper mode, the amount of blue light emitted from the screen is reduced by changing the color tone and
controlling the brightness.
14
Chapter 2 Basic Adjustment / Setting

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
