Eizo FlexScan EV2785 User Manual

4-2. Functions of the “Administrator Settings” Menu
Function
Setting
Range
Description
Auto Input Detection On
Off
This function automatically recognizes the connector through which
PC signals are input, and displays images on the screen accordingly.
- “On”
When the monitor is connected to multiple PCs, if a specic PC
enters power saving mode or no signals are input to the monitor,
the connector is automatically changed to another one to which
signals are input.
- “Off”
This function displays the signal from the selected connector
regardless of whether a signal is input or not. In this case, you can
select the input signal to display using the
operation switch
on the front of the monitor. For details, see “2-2. Switching Input
Signals” (page 13).
Note
• This function is not available during PbyP display.
• This product automatically recognizes the connector through
which PC signals are input, and displays images on the screen
accordingly regardless of whether this function is set to On or Off
just after the main power switch on the rear side of the monitor
has been turned on.
• When this function is set to “On”, the monitor only enters the
power saving mode when signals are not input from any PC.
Compatibility Mode On
Off
If you want to avoid the following phenomena, set this function to
"On".
• The positions of windows and icons are shifted when the monitor
is turned off / on or has returned from the power saving mode.
• Power Save function of the PC does not work normally.
• During USB-C input, the screen blinks two or three times
immediately after the USB cable has been connected or the PC
has returned from the Power Save mode.
• When the power to the monitor is turned off, a device connected
to the USB downstream port does not work.
USB-C 4K UHD 60Hz /
USB2.0
4K UHD 30Hz /
USB3.1
The USB setting and the types of signals that the monitor can display
can be changed.
DisplayPort Version 1.1
Version 1.2
The types of signals that the monitor can display can be changed.
HDMI 1 4K UHD 60Hz
4K UHD 30Hz
The types of signals that the monitor can display can be changed.
Note
• If the HDMI signal that is being input is not displayed, change
this setting.
26
Chapter 4 Administrator Settings

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
