Eizo FlexScan EV2785 User Manual

6-4. Connecting Multiple PCs
This product can be connected to multiple PCs and allows you to switch between the connections for
display.
●
Connection examples
DisplayPort
HH200PR (HDMI - HDMI) HDMIHDMI
PP200 (DisplayPort - DisplayPort) DisplayPort
USB-C CC200SS (USB-C - USB-C) USB-C
(supplied)
(supplied)
(supplied)
Note
• You can select the input signal to display using the operation switch on the front of the monitor. For details, see
“2-2. Switching Input Signals” (page 13).
• This product provides a function that automatically recognizes the connector through which PC signals are input,
and displays images on the screen accordingly. For details, see “Auto Input Detection” (page 26).
36
Chapter 6 Reference

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
