Eizo FlexScan EV2785 User Manual

Chapter 1 Introduction
Thank you very much for choosing an EIZO color LCD monitor.
1-1. Features
●
Support for DisplayPort over USB Type-C (DP Alt Mode) / USB Power
Delivery
This product is equipped with a USB Type-C (USB-C) connector compatible with DP Alt Mode and
USB Power Delivery.
• While being used as an external monitor of a notebook PC, this product can supply power to the
PC.
Video Signals
Power Supply
• While displaying photos and motion pictures from a smartphone or tablet, this product can charge
the device.
100%
Video Signals
Power Supply
Note
• Devices to be connected must be equipped with a USB-C connector, and support the charging function
based on USB-C or USB Power Delivery.
• The device connected to the monitor can be charged even when the monitor is in power saving mode.
6
Chapter 1 Introduction

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
