Eizo FlexScan EV2785 User Manual

●
Preference Settings
The monitor’s settings can be congured to suit the usage environment or personal preference.
Function
Setting
Range
Description
Menu Rotation 0°
90°
Change the orientation of the Setting menu when using the monitor screen in
the portrait display position.
Note
• Make sure that the cables are correctly connected.
• PC settings must be congured to use the monitor in a portrait position.
For details, refer to our web site (http://www.eizoglobal.com).
USB CHARGE
Port
Normal
Charging Only
The USB downstream port of the monitor supports boost charging via
USB 3.0. By changing this setting to “Charging Only”, the device connected
to the
port can be charged in a shorter period of time than that which
would be required when it is set to “Normal”.
Note
• Before changing this setting, terminate communication between the
PC any USB devices connected to the monitor. All communication is
temporarily interrupted when the setting is changed.
• The device connected to the
port must support boost charging.
• When this is set to “Charging Only”, data communication cannot be
established between the device connected to the
port and the PC,
and the device will not operate.
• When this is set to “Charging Only”, charging is possible even when the
monitor is not connected to the PC using a USB cable.
Power Save On
Off
The monitor can be set to enter power saving mode according to the state of
the PC.
The monitor changes to power saving mode about 15 seconds after signal
input ceases to be detected.
When the monitor has shifted to power saving mode, images are not
displayed on the screen.
• Exiting power saving mode
- If the monitor receives input, it automatically exits power saving mode
and returns to the normal display mode.
Note
• At the time of shifting to power saving mode, a message that indicates
the transition is displayed 5 seconds in advance.
• During PbyP display, the monitor only enters the power saving mode
when signals are not input from both PCs.
• When not using the monitor, you can turn off the main power supply or
disconnect the power plug so that the power is cut completely.
• When the monitor is in power saving mode, devices connected to the
USB downstream port will still work. Therefore, power consumption of
the monitor varies with connected devices even in power saving mode.
Power Indicator On
Off
The power indicator (white) can be turned off during screen display.
23
Chapter 3 Advanced Adjustment / Setting

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
