Eizo FlexScan EV2785 User Manual

5-2. Imaging Problems
Problem Possible cause and remedy
1. The screen is too bright or too
dark.
• Use “Brightness” or “Contrast” in the Setting menu to adjust it (see
“Color Adjustment” (page 19)). (The LCD monitor backlight has
a limited life span. If the screen becomes dark or begins to icker,
contact your local EIZO representative.)
• If the screen is too bright, try changing the Auto EcoView setting
to “On”. The monitor detects the ambient brightness to adjust the
screen brightness automatically (see “Auto EcoView” (page 16)).
2. Brightness cannot be changed or
it changes on its own.
• Try changing the Auto EcoView setting to “Off” (see “Auto EcoView”
(page 16)).
3. Text is blurred. • Check whether the PC is congured to meet the resolution and
vertical scan frequency requirements of the monitor (see “1-3.
Supported Resolutions” (page 10)).
4. Afterimages appear. • Afterimages are particular to LCD monitors. Avoid displaying the
same image for a long time.
• Use the screen saver or power saving function to avoid displaying
the same image for extended periods of time. Depending on the
image, an afterimage may appear even if it was displayed for a short
period of time. To remove such a phenomenon, change the image
or keep the power turned off for several hours.
5. Green / red / blue / white / dark
dots remain on the screen.
• This is due to LCD panel characteristics and not a malfunction.
6. Interference patterns or pressure
marks remain on the screen.
• Leave the monitor with a white or black screen. The symptom may
disappear.
7. Noise appears on the screen. • In the Setting menu, set “Overdrive” to “Off” (see “Overdrive” (page
21)).
• When inputting HDCP system signals, normal images may not be
displayed immediately.
8. The positions of windows and
icons are shifted when the
monitor is turned off / on or when
restored from power saving mode.
• Turn the setting “On” for “Compatibility Mode” on the “Administrator
Settings” menu (see “Compatibility Mode” (page 26)).
8. The color shown on the screen is
not correct.
• Try changing “Input Color Format” in the Setting menu (see “Input
Color Format” (page 22)).
9. Images are not displayed over the
entire area of the screen.
• Try changing “Picture Expansion” in the Setting menu (see “Picture
Expansion” (page 22)).
29
Chapter 5 Troubleshooting

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
