Eizo FlexScan EV2785 User Manual

Power Input 100 - 240 VAC ±10 %, 50 / 60 Hz 1.65 A - 0.75 A
Maximum Power
Consumption
163 W or less
Power Save Mode 0.5 W or less (no USB device connected, default settings)
Standby Mode 0.5 W or less (no USB device connected, default settings)
Physical
Specications
Dimensions 611.4 mm × 370.1 mm to 565.1 mm × 235.8 mm to 270.2 mm
(W × H × D) (Tilt: 35˚)
611.4 mm × 367.3 mm to 545.2 mm × 230 mm
(W × H × D) (Tilt: 0˚)
Dimensions
(Without Stand)
611.4 mm × 356.3 mm × 50.0 mm (W × H × D)
Net Weight Approx. 8.2 kg
Net Weight (Without
Stand)
Approx. 4.9 kg
Height Adjustment
Range
195 mm (Tilt: 35˚) / 177.9 mm (Tilt: 0˚)
Tilt Up 35˚, down 5˚
Swivel 344˚
Vertical Rotation Right 90°
Operating
Environmental
Requirements
Temperature 5 ˚C to 35 ˚C
Humidity 20 % to 80 % R.H. (no condensation)
Air Pressure 540 hPa to 1060 hPa
Transportation /
Storage
Environmental
Requirements
Temperature -20 ˚C to 60 ˚C
Humidity 10 % to 90 % R.H. (no condensation)
Air Pressure 200 hPa to 1060 hPa
*1 HDMI CEC (or mutual control) is not supported.
*2 Only Gen1 5 Gbps is supported.
●
Accessories
Cleaning Kit EIZO “ScreenCleaner”
For the latest information about accessories, refer to our web site. http://www.eizoglobal.com
39
Chapter 6 Reference

Eizo FlexScan EV2785 Specifications

General

AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	162 W
Power consumption (standby)	0.5 W
Power consumption (typical)	27.7 W
3D	No
Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Response time	14 ms
Display diagonal	27 \
Display technology	LED
Native aspect ratio	16:9
Viewable size, vertical	335.7 mm
Display number of colors	16.78 million colors
Viewable size, horizontal	596.7 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 720 x 576, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 2160, 3840 x 2160
Power management	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Headphone connectivity	3.5 mm
USB upstream port type	USB Type-C
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	2
Certification	CE, CB, TÜV/GS, TÜV/Ergonomics (including ISO 9241-307), TCO Certified Generation 8, EPEAT 2018 (US), TÜV/Blue Low Light Content, TÜV/Flicker Free, RCM, cTÜVus, FCC-B, CAN ICES-3 (B), TÜV/S, PSE, VCCI-B, EPA ENERGY STAR, RoHS, WEEE, China RoHS, CCC, EAC
Product color	Black
RMS rated power	2 W
Pivot angle	-45 - 45 °
Cable lock slot type	Kensington
Tilt down angle range	- °
Number of OSD languages	9
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), DEU, ENG, ESP, FRE, ITA, JPN, SWE
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Sustainability certificates	CB, CCC, CE, China RoHS, EAC, ENERGY STAR, EPEAT Bronze, Federal Communications Commission (FCC), ICES, PSE, RCM, RoHS, TUV, VCCI, WEEE, cTUVus
Cables included	AC
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	230 mm
Height (with stand)	545.2 mm
Weight (with stand)	8200 g
Depth (without stand)	50 mm
Width (without stand)	611.4 mm
Height (without stand)	356.3 mm
Weight (without stand)	4900 g
